BIOPURE 120 (230V)
BIOPURE 120 (230V) BIOPURE 120 (230V)

BIOPURE 120 (230V)

Part Number: MB120XXM1-230

Quick Overview

The BIOPURE 60/120 has been specifically designed to deliver compliant purified water at the point of use for a wide range of washer disinfectors and endoscope reprocessors to minimize contamination risk to patients.



Reliable water quality – unique disinfection design for purification of RO membranes as well as the local distribution loop


Guaranteed bacterial specification, provided by integrated purification technologies combined with easy system disinfection


Space saving – “all in one” design allows easy under-bench installation Economic design – unique “wrap around” reservoir


Unique system operation protection using automated alarms and access to important control systems limited by “E-key”




  • General
  • System Performance
  • Dimensions & Weights
  • Feed Water
  • Installation
Main Feature

The BIOPURE 60/120 has been specifically designed to deliver compliant purified water at the point of use for a wide range of washer disinfectors and endoscope reprocessors to minimize contamination risk to patients.


Reliable water quality – unique disinfection design for purification of RO membranes as well as the local distribution loop

Guaranteed bacterial specification, provided by integrated purification technologies combined with easy system disinfection

Space saving – “all in one” design allows easy under-bench installation Economic design – unique “wrap around” reservoir

Unique system operation protection using automated alarms and access to important control systems limited by “E-key”


Local SKU MB120XXM1-230
Brand Name Range BIOPURE
Validation Support Available Yes
Applications Automated Endoscope Reprocessor, Endoscopy, ENT (ears, nose & throat) Washer disinfector, General rinsing, Ultra sonic bath, Washer disinfectors
Video/Brochure
Make-Up Rate 120 l/hr
Delivery Flow Rate up to 10 l/min
Daily Usage (8hr day) > 100 l/day
Inorganics <30 μS/cm
Bacteria <0.1 CFU/ml (<1 CFU/10ml)
Endotoxins <0.25 EU/ml
Footnotes Bacteria - Specification subject to system being installed and regularly disinfected following ELGA installation design guidelines. Sample to be taken from hygienic sample valve and sampled in accordance with ELGA guidelines
Inorganics - Specification can be improved to <5 μS/cm subject to optional deionisation cartridge fitted.
Height (mm(inch)) 820 (32.3)
Width (mm(inch)) 790 (31.1)
Depth (mm(inch)) 480 (18.9)
Operating Weight (kg(lb)) 115 (254)
Footnotes Installation - Ensure installed within a properly vented area
Feedwater Nature Potable supply (Tap Water)
Conductivity <1400 µS/cm
Fouling Index <10
Free Chlorine <1 ppm
Temperature 15-25 °C
Flow Rate 10 l/min
Drain (gravity fall with air gap) 20 l/min
Min. Pressure 2 bar (30 psi)
Max. Pressure 6 bar (90 psi)
Installation Options Floor mounted, Under bench
Mains Input 230V ac, 50 Hz
System Voltage 24V DC
Power Consumption 800 VA (Peak demand)
Fuses 13 amps
Noise Level <60 dBA
