BIOPURE 15 (With Boost Pump & 25 liter Docking Vessel)
BIOPURE 15 (With Boost Pump & 25 liter Docking Vessel) BIOPURE 15 (With Boost Pump & 25 liter Docking Vessel) BIOPURE 15 (With Boost Pump & 25 liter Docking Vessel)

BIOPURE 15 (With Boost Pump & 25 liter Docking Vessel)

Part Number: MB015PK01

Quick Overview

The BIOPURE 7/15 has been designed to deliver compliant purified water at the point of use for a wide range of washer disinfectors and autoclaves to minimize contamination risk to patients.




• Cost effective – provides the convenience of on-demand pure water at a price comparable with purified bottled water
• Space saving – the BIOPURE’S compact size means that it can be positioned under a bench, wall mounted or fitted into a cabinet
• Guaranteed bacterial specification, provided by integrated purification technologies combined with easy system disinfection
• Water specification is maintained in the reservoir by regular recirculation through the purification technologies




  • General
  • System Performance
  • Dimensions & Weights
  • Feed Water
  • Installation
Main Feature

The BIOPURE 7/15 has been designed to deliver compliant purified water at the point of use for a wide range of washer disinfectors and autoclaves to minimize contamination risk to patients.


• Cost effective – provides the convenience of on-demand pure water at a price comparable with purified bottled water
• Space saving – the BIOPURE’S compact size means that it can be positioned under a bench, wall mounted or fitted into a cabinet
• Guaranteed bacterial specification, provided by integrated purification technologies combined with easy system disinfection
• Water specification is maintained in the reservoir by regular recirculation through the purification technologies


Brand Name Range BIOPURE
Validation Support Available Yes
Applications Automated Endoscope Reprocessor, Endoscopy, ENT (ears, nose & throat) Washer disinfector, General rinsing, Ultra sonic bath, Washer disinfectors
Make-Up Rate 15 l/hr
Delivery Flow Rate up to 2 l/min
Daily Usage (8hr day) < 100 l/day
Inorganics <1 μS/cm
Bacteria <0.1 CFU/ml (<1 CFU/10ml)
Endotoxins <0.25 EU/ml
Footnotes Bacteria - Specification subject to system being installed and regularly disinfected following ELGA installation design guidelines. Sample to be taken from hygienic sample valve and sampled in accordance with ELGA guidelines
Height (mm(inch)) 554 (21.7)
Width (mm(inch)) 550 (21.7)
Depth (mm(inch)) 362 (14.3)
Operating Weight (kg(lb)) 52 (115)
Footnotes Installation - Ensure installed within a properly vented area
Height - When fitted with composite vent filter 584mm
Operating Weight - Docking vessels weights 31kg when full
Feedwater Nature Potable supply (Tap Water)
Conductivity <1400 µS/cm
Fouling Index <10
Silica <30 ppm
Temperature 15-25 °C
Flow Rate 1.4 l/min
Drain (gravity fall with air gap) 1.2 l/min
Min. Pressure Flooded suction with internal boost pump
Max. Pressure 2 bar (30 psi) with internal boost pump
Installation Options Bench, Under bench, Wall
Mains Input 100-240V ac, 50-60 Hz
Fuses 13 amps
Noise Level <45 dBA
