PURELAB FLEX 2 - TYPE I ULTRAPURE WATER

PURELAB FLEX 2 - TYPE I ULTRAPURE WATER

Part Number: PF2XXXXM1

Quick Overview

The PURELAB flex 2 uniquely combines ease of use with the accurate delivery of pure water. The flexible modular system can be configured to deliver the quality of water you need for your applications and includes UV photo-oxidation and TOC monitoring

Daily volume: >10 Litres

Water quality: Type I ultrapure water

Add to Wishlist

General
System Performance
Dimensions & Weights
Feed Water
Installation

Main Feature	The PURELAB flex 2 uniquely combines ease of use with the accurate delivery of pure water. The flexible modular system can be configured to deliver the quality of water you need for your applications and includes UV photo-oxidation and TOC monitoring Daily volume: >10 Litres Water quality: Type I ultrapure water
Brand Name Range	PURELAB
Validation Support Available	Yes

Delivery Flow Rate	up to 2 l/min
Daily Usage (8hr day)	< 100 l/day
Inorganics	18.2 MΩ-cm
Organics (TOC)	<5 ppb
Bacteria	<0.1 CFU/ml (<1 CFU/10ml)
Endotoxins	<0.001 EU/ml
DNase	<20 pg/ml
RNase	0.002 ng/ml
Footnotes	Bacteria - Specification subject to use with a POU (point of use) Biofilter. If Microfilter is used, then Bacteria level is <1 CFU/ml TOC - Specification dependant on feedwater Endotoxin - Specification subject to use with a Biofilter DNase/RNase - Specification subject to use with a Biofilter

Height (mm(inch))	900 (35.4)
Width (mm(inch))	236 (9.3)
Depth (mm(inch))	374 (14.7)
Operating Weight (kg(lb))	11 (24)
Footnotes	Flexible Height - 900 to 1020 mm

Feedwater Nature	Pre-treated (RO/SDI/Distilled)
Fouling Index	<1
Free Chlorine	<0.05 ppm
Carbon Dioxide	<0.1 ppm
Silica	<2 ppm
Organics (TOC)	<20 ppb
Flow Rate	>2 l/min
Drain (gravity fall with air gap)	None required
Min. Pressure	Flooded suction
Max. Pressure	1.5 Bar
Footnotes	Pokud je vodivost vstupn?? vody v rozmez?? 1 - 30 ?S/cm, budete pot??ebovat p??edupravovac?? kit.
