PURELAB Option S 15 (With Boost Pump)
PURELAB Option S 15 (With Boost Pump) PURELAB Option S 15 (With Boost Pump) PURELAB Option S 15 (With Boost Pump)

PURELAB Option S 15 (With Boost Pump)

Part Number: OS015BPM1

Quick Overview

The PURELAB Option provides Type II+/II pure water on demand with a wide range of flow-rates to suit your needs. Applications range from glassware washing and the feeding of ultrapure water systems to cell culture and media preparation. The PURELAB Option-R provides additional bacteria and inorganic quality for your more critical applications.



Delivers market leading microbial performance. In addition to simple sanitization and composite vent filtration, the PURELAB Option-R system is the only fully recirculating Type II+ pure water system on the market, ensuring high specification water



Features ‘Reverse Osmosis feed optimized’ resin mixes to increase the ion exchange capacity of consumables and minimize running costs



Quick and easy sanitization and replacement of consumables to reduce maintenance time



PURELAB Option systems are designed to be easy to access whether wall or bench mounted with a convenient dispense tap. They can be used with our wrap-around reservoirs to save space whilst optimizing purity




  • General
  • System Performance
  • Dimensions & Weights
  • Feed Water
  • Installation
Main Feature

The PURELAB Option provides Type II+/II pure water on demand with a wide range of flow-rates to suit your needs. Applications range from glassware washing and the feeding of ultrapure water systems to cell culture and media preparation. The PURELAB Option-R provides additional bacteria and inorganic quality for your more critical applications.


Delivers market leading microbial performance. In addition to simple sanitization and composite vent filtration, the PURELAB Option-R system is the only fully recirculating Type II+ pure water system on the market, ensuring high specification water


Features ‘Reverse Osmosis feed optimized’ resin mixes to increase the ion exchange capacity of consumables and minimize running costs


Quick and easy sanitization and replacement of consumables to reduce maintenance time


PURELAB Option systems are designed to be easy to access whether wall or bench mounted with a convenient dispense tap. They can be used with our wrap-around reservoirs to save space whilst optimizing purity


Brand Name Range PURELAB
Validation Support Available Yes
Applications Boiler feed, Feed Autoclave / steriliser, Feed to ultra pure water systems, Forklift battery water, General chemistry, General rinsing, Glassware washing/rinsing, Steam generators, Steriliser feed
Make-Up Rate 15 l/hr
Daily Usage (8hr day) < 100 l/day
Organics (TOC) <30 ppb
Particles N/A
Height (mm(inch)) 460 (18.1)
Width (mm(inch)) 410 (16.1)
Depth (mm(inch)) 270 (10.6)
Operating Weight (kg(lb)) 16.5 (36)
Feedwater Nature Potable supply (Tap Water)
Conductivity <1400 µS/cm
Fouling Index <10
Free Chlorine <0.5 ppm
Silica 30 ppm
Temperature 1-35 °C
Flow Rate <85 l/hr
Drain (gravity fall with air gap) 70 l/hr
Min. Pressure Flooded suction with internal boost pump
Max. Pressure 2 bar (30 psi) with internal boost pump
Installation Options Bench, Wall
Mains Input 100-240V ac, 50-60 Hz
System Voltage 24V DC
Power Consumption 43 VA (with boost pump)
Fuses 2 x T3.15 amp
Reservoir Connection Jack plug 3.5 mm
Noise Level <45 dBA
